Drafting 1 -- Accurate Grid

7th Grade Industrial Technology Description/Standards

  • 1. Demonstrate knowledge of fractions as used in measurements.
  • 1a. Understand how to read metric and english ruler measurements.
  • 1b. Understand how to add and subtract fractions in half and quarter increments.
  • 1c. Use rulers to draw accurately measured lines.
  • 1d. Use rulers to draw simple shapes to scale.

  • 2. Demonstrate knowledge and skills in giving paper structural strength.
  • 2a. Understand real world applications of folds to improve structure/strength.
  • 2b. Create Paper self-supporting paper towers.
  • 2c. Create paper bridges.
  • 2c. Create flying paper airplanes.

  • 3. Demonstrate knowledge and use of the technical skills of leather working.
  • 2a. Understand real world applications of leather work.
  • 2b. Understand and apply leather working techniques to make a bookmark.
  • 2c. Clean and finish leather.

  • 4. Understand mechanics of gears and simple machines.
  • 4a. Understand real world applications of gears/wheels in transportation.
  • 4b. Understand gear ratios.
  • 4c. Follow directions to create simple lego machines.
  • 4d. Create original machines without directions

  • 5. Make a wood craft cut-out.
  • 5a. Understand woodworking tools and safety precautions.
  • 5b. Use wood working tools to cut and smooth a simple shape.
  • 5c. Use paints, stains and varnish to finish project.



    • T-square and triangle use is demonstrated:

    Students are shown how to square their paper with a t-square and tape it down.

    A short demonstration of t-square and triangle use are shown along with the use of a ruler to get accurate measurements.

    Students are to draw a half inch border around their paper and a 1/4 inch grid inside the border. After which they may color various designs on their gridded paper.

    Evaluation:

    3 points -- Even/consistent lines
    4 points -- Accurately measured grid
    3 points -- Creative and interesting colored design
    10 Points total
